IPL group supply a range of surface boxes and access covers and gratings for all roads utilities; water pipeline connections and electrical installations. Both these items have the benefit of light transport and easy on-site assembly. IPL group also design and manufacture the ORBITAL range of access covers and gratings to meet customer requirements for a quality and competitive supply. All covers and gratings hold European Standard EN124 with Kitemark certification and appropriate load classification.
Ductile Iron
Material Standard - EN-GJS-500-7
Product Standards - EN124 - Classes B125 / C250 / D400
Kitemark - BSI Certification
VALVE COVERS & FRAME RANGE
Stopcock
Mars Sluice Valve, B125
Mars Air Valve, B125
Mars Hydrant, B125
Mars Water Meter, B125
Single Cover
Non-Rock Action
Markings on Covers
Security Chain
Black Bitumen Coated
Customised Badging Option
Customised Colour Coating Option
Frame Opening: 445x275mm
Frame Size: 575x410mm
Frame Depth: 65mm
Weight: 21kg
Ductile Iron (Spheroidal Graphite)
EN-GJS-500-7 (Material Standard)
EN124 - Class B125 (Product Standard)
Kitemark (BSI Certification)
Sluice Valve (Small)
Venus Sluice Valve, D400
Venus Air Valve, D400
Venus Hydrant, D400
Venus Water Meter, D400
Double Triangular Covers
Non-Rock Action
Double Bolt Secured Sections
Cover Markings on Both Sections
Open Keyholes
Security Chain
Black Bitumen Coated
Customised Badging Option
Customised Colour Coating Option
Frame Opening: 445x280mm
Frame Size: 645x480mm
Frame Depth: 100mm
Weight: 39kg
Ductile Iron (Spheroidal Graphite)
EN-GJS-500-7 (Material Standard)
EN124 - Class D400 (Product Standard)
Kitemark (BSI Certification)
MANHOLE COVERS & FRAMES RANGE
Saturn B125 Round
Manhole Cover & Frame
Footpaths, Pedistrian Areas
Car Parks or Car Parking Decks
Single Cover
Non-Rock Action
Single Seal Groove
Dowel Setting
Closed Keyholes
Black Bitumen Coated
Security Screw Lock Option
Customised Badging Option
Customised Colour Coating Option
Frame Opening: 550mm
Frame Size: 670mm
Frame Depth: 60mm
Weight: 33kg
Ductile Iron (Spheroidal Graphite)
EN-GJS-500-7 (Material Standard)
EN124 - Class B125 (Product Standard)
Kitemark (BSI Certification)
Punto D400 Round
Manhole Cover & Frame
GROUP 4
Carriageways of Roads
Pedestrian Streets
Hard Shoulders & Parking Areas
Single Hinged Cover
Non-Rock Action
Secure Locking Mechanism
Open / Lock Directions on Cover
Cover Opens Clear to 115° Angle
Removable Cover
Sound proof joint included
Closed Keyholes
Black Bitumen Coated
Customised Colour Coating Option
Frame Opening: 600mm
Frame Size: 825mm
Frame Depth: 100mm
Weight: 20kg
Ductile Iron (Spheroidal Graphite)
EN-GJS-500-7 (Material Standard)
EN124 - Class D400 (Product Standard)
Delta D400 Round
Manhole Cover & Frame
GROUP 4
Carriageways of Roads
Pedestrian Streets
Hard Shoulders & Parking Areas
Single Hinged Cover
Non-Rock Action
Secure Locking Mechanism
Open / Lock Directions on Cover
Cover Opens Clear to 130° Angle
Removable Cover
Sound proof joint included
Closed Keyholes
Black Bitumen Coated
Customised Colour Coating Option
Frame Opening: 810mm
Frame Size: 1000x1000mm
Frame Depth: 100mm
Weight: 20kg
Ductile Iron (Spheroidal Graphite)
EN-GJS-500-7 (Material Standard)
EN124 - Class D400 (Product Standard)
Saturn B125 square
Manhole Cover & Frame
GROUP 2
Footways
Pedestrian Areas
Car Parks & Parking Decks
Single Cover
Non-Rock Action
Single Seal Groove
Dowel Setting
Closed Keyholes
Black Bitumen Coated
Customised Badging Option
Customised Colour Coating Option
Frame Opening: 550mm
Frame Size: 670mm
Frame Depth: 60mm
Weight: 35kg
Ductile Iron (Spheroidal Graphite)
EN-GJS-500-7 (Material Standard)
EN124 - Class B125 (Product Standard)
Kitemark (BSI Certification)
Neptune D400 square
Manhole Cover & Frame
GROUP 4
Carriageways of Roads
Pedestrian Streets
Hard Shoulders & Parking Areas
Double Triangular Covers
Non-Rock Action
Double Bolt Secured Sections
Closed Keyholes
Black Bitumen Coated
Customised Badging Option
Customised Colour Coating Option
Frame Opening: 600x600mm
Frame Size: 760x760mm
Frame Depth: 100mm
Weight: 79kg
Ductile Iron (Spheroidal Graphite)
EN-GJS-500-7 (Material Standard)
EN124 - Class D400 (Product Standard)
Kitemark (BSI Certification)
KDAX19 D400 Square
Manhole Cover & Frame
GROUP 4
Carriageways of Roads
Pedestrian Streets
Hard Shoulders & Parking Areas
Anti-movement frame technology
Easy to open cover
Locking mechanism as standard
Sequenced opening - single point locking
Non-rock three point suspension for stability
Mechanical lifting points
Black non-slip coated finish to BS 3416
Customised Colour Coating Option
Frame Opening: 1220x675mm
Frame Size: 1380x835mm
Frame Depth: 100mm
Weight: 199kg
Ductile Iron (Spheroidal Graphite)
ISO 1083 (Material Standard)
EN124 - Class D400 (Product Standard)
VALVE COVERS & FRAMES RANGE
Sita B125 Sluice Valve
Cover & Frame
GROUP 2
Footways
Pedestrian Areas
Car Parks & Parking Decks
Single Hinged Cover
Non-Rock Action
Open Keyhole
Black Bitumen Coated
Customised Badging Option
Frame Opening: 125x128mm
Frame Size: 195x200mm
Frame Depth: 50mm
Weight: 3.6kg
Ductile Iron (Spheroidal Graphite)
EN-GJS-500-7 (Material Standard)
EN124 - Class B125 (Product Standard)
Kitemark (BSI Certification)
Ida B125 Sluice Valve
Cover & Frame
GROUP 2
Footways
Pedestrian Areas
Car Parks & Parking Decks
Single Hinged Cover
Non-Rock Action
Open Keyhole
Black Bitumen Coated
Customised Badging Option
Frame Opening: 125x128mm
Frame Size: 195x200mm
Frame Depth: 100mm
Weight: 6kg
Ductile Iron (Spheroidal Graphite)
EN-GJS-500-7 (Material Standard)
EN124 - Class B125 (Product Standard)
Kitemark (BSI Certification)
Juno D400 Sluice Valve
Cover & Frame
GROUP 4
Carriageways of Roads
Pedestrian Streets
Hard Shoulders & Parking Areas
Single Hinged Cover
Non-Rock Action
Double Bolt Secured Sections
Cover Markings On Both Sections
Open Keyhole
Black Bitumen Coated
Customised Badging Option
Frame Opening: 150x150mm
Frame Size: 250x250mm
Frame Depth: 155mm
Weight: 13.6kg
Ductile Iron (Spheroidal Graphite)
EN-GJS-500-7 (Material Standard)
EN124 - Class D400 (Product Standard)
Kitemark (BSI Certification)
GULLY GRATINGS
Tyche D400
Flat Gully Grating
GROUP 4
Carriageways of Roads
Pedestrian Streets
Hard Shoulders & Parking Areas
Double Triangular Covers
Non-Rock Action
Flat Grating
Double Bolt Secured Sections
Full Frame Flange
Black Bitumen Coated
Frame Opening: 600x600mm
Frame Size: 750x750mm
Frame Depth: 100mm
Weight: 95kg
Waterway Area: 1809cm²
Ductile Iron (Spheroidal Graphite)
EN-GJS-500-7 (Material Standard)
EN124 - Class D400 (Product Standard)
Kitemark (BSI Certification)
Kolga D400
Flat Gully Grating
GROUP 4
Carriageways of Roads
Pedestrian Streets
Hard Shoulders & Parking Areas
Double Triangular Covers
Non-Rock Action
Flat Grating
Double Bolt Secured Sections
Three-Sided Frame Flange
Flush Kerbside Finish
Black Bitumen Coated
Frame Opening: 400x440mm
Frame Size: 550x527mm
Frame Depth: 100mm
Weight: 41.5kg
Waterway Area: 1001cm²
Ductile Iron (Spheroidal Graphite)
EN-GJS-500-7 (Material Standard)
EN124 - Class D400 (Product Standard)
Kitemark (BSI Certification)
Pallas C250
Flat Gully Grating
GROUP 3
For gully tops installed in the area of kerbside channels of roads which when measured from the kerb edge, extends to a maximum of 0.5m into the carriageway and a maximum of 0.2m into the footway.
Single Hinged Cover
Non-Rock Action
Flat Grating
Locking Bolt
Three-Sided Frame Flange
Flush Kerbside Finish
Recessed End Hinge
Black Bitumen Coated
Customised Locking Option
Frame Opening: 365x310mm
Frame Size: 514x400mm
Frame Depth: 75mm
Weight: 24kg
Waterway Area: 674cm²
Ductile Iron (Spheroidal Graphite)
EN-GJS-500-7 (Material Standard)
EN124 - Class C250 (Product Standard)
Kitemark (BSI Certification)
Vesta C250
Concaved Grating
GROUP 3
For gully tops installed in the area of kerbside channels of roads which when measured from the kerb edge, extends to a maximum of 0.5m into the carriageway and a maximum of 0.2m into the footway.
Single Hinged Cover
Non-Rock Action
Concaved Grating
Locking Bolt
Full Frame Flange
Flush Kerbside Finish
Recessed End Hinge
Black Bitumen Coated
Customised Locking Option
Frame Opening: 390x315mm
Frame Size: 590x520mm
Frame Depth: 75mm
Weight: 24kg
Waterway Area: 725cm²
Ductile Iron (Spheroidal Graphite)
EN-GJS-500-7 (Material Standard)
EN124 - Class C250 (Product Standard)
Kitemark (BSI Certification)
Multi-Leaf D400
Manhole Cover & Frame
GROUP 4
Carriageways of Roads
Pedestrian Streets
Hard Shoulders & Parking Areas
Two Triangular Hinged Covers
Can be opened separatley
Non-Rock Action
Easy Open Hinge
Secure Exploration
120° Maximum Opening
Cannot Accidentally Close
Flush Kerbside Finish
Black Painted Coated
Slip Proof Surface
Frame Opening: 760x1540mm
Frame Size: 880x1650mm
Frame Depth: 75mm
Weight: 24kg
Ductile Iron (Spheroidal Graphite)
EN-GJS-500-7 (Material Standard)
EN124 - Class D400 (Product Standard)
