AGRULINE Electrofusion Fittings

The AGRULINE system of pipework products encompasses a broad range of electrofusion fittings such as couplers, bends, tees, reducers and end caps, all produced from PE 100-RC

  • Enormous stress crack resistance thanks to robust PE 100-RC
  • No sand embedding required, saving costs during laying
  • Perfectly harmonised for all AGRULINE pipes
  • Permanently leak-tight connections through butt, socket or electro-socket welding
  • Simple assembly of the electro-socket fittings thanks to chamfered inlets and long insertion depths
  • Simple to weld, even where little space is available or terrain is difficult

    • AGRULINE Fittings Range

    Multi-bends – multi-functional

  • Stable bends suitable for butt and electro-socket welding
  • Top flexibility – can be used as a long-spigot or, when cut, as a short-spigot fitting
  • Suitable for Potable Water, Gas & Waste Water

    • Product Range
  • SDR 17 - OD 63mm - 315mm
  • SDR 11 - OD 20mm - 315mm

    • Elongated Fittings

    Elongated fittings – improved flexibility when welding
  • Compatible with butt welding and electro-socket welding for flexibility in applications
  • Low-stress thanks to optimised gate system
  • Suitable for Potable Water, Gas & Waste Water

    • Product Range
  • SDR 17 - OD 63mm - 500mm*
  • SDR 11 - OD 20mm - 500mm*
  • * Stub flanges up to OD 710 mm

    • Segmented Fittings

    Segmented fittings are available in dimensions up to OD 2500 mm and are designed and harmonised to the customer's specific specifications
  • Solutions with or without de-rating factor for pressure available
  • Top flexibility, as pieces are produced to meet the customer's requirements
  • Expert workmanship and strict QA ensure identical performance to standard fittings
  • Suitable for Potable Water & Waste Water

    • Product Range
  • SDR 41 - OD 560mm - 2500mm
  • SDR 33 - OD 560mm - 2500mm
  • SDR 26 - OD 560mm - 2500mm
  • SDR 17 - OD 560mm - 2500mm
  • SDR 11 - OD 560mm - 1600mm

    • Customised Fittings

    Customized fittings – in accordance with your needs
  • Customized fittings are available in dimensions up to OD 2500
  • Designed according to customer requirements to ensure a perfect fit
  • Reduced overall costs through perfect integration in any construction plans
  • Pressure-rated versions available by request
  • Suitable for Potable Water, Gas & Waste Water

    • Product Range
  • OD 560mm - 2500mm

    • Heated tool socket fittings

    Heated tool socket fittings – in small dimensions
  • Compact fittings for fast connections using heated tool socket welding
  • Easy to handle, even at limited space conditions
  • Affordable solution and affordable welding equipment
  • Suitable for Potable Water, Gas & Waste Water

    • Product Range
  • OD 20mm - 110mm

    • Sweep bends

    Sweep bends - for low flow resistance joinings.
  • Unimpeded flow of media thanks to smooth inner surface and large radius
  • Bent but stable pipes - available in many dimensions and angles
  • Full pressure resistance
  • For gas and potable water
  • Suitable for heated tool butt welding and electro-socket welding

    • Product Range
  • SDR 17 - OD 90mm - 800mm
  • SDR 11 - OD 590mm - 800mm
  • Bend radiuses - 11°, 22°, 30°, 45°, 60°, 90°

    • AGRU SDR 7.4 pipes and fittings

    AGRU SDR 7.4 pipes and fittings – for high-pressure applications
  • Thick walls can handle water pressure up to 25 bar
  • Extensive range of products, including injection-moulded fittings
  • Strong static ratings for maximum safety in practical applications
  • Fits SDR 7.4 pipes in dimensions from 63 – 500 mm
  • Suitable for Potable Water & Waste Water

    • Product Range
  • SDR 7.4 - OD 63mm - 500mm

    • FM approved pipes and fittings

    FM approved pipes and fittings – for reliable underground fire protection lines
  • FM approved for top reliability in emergency situations
  • Corrosion-free, eliminating threat of sprinkler clogging
  • Subject to 4x maximum pressure during certification to ensure top safety
  • Suitable for potable water

    • Product Range
  • 175 psi - OD 63mm - 500mm
  • 200 psi - OD 63mm - 500mm

    • Short-spigot fittings

    Short-spigot fittings – for heated tool butt welded pipelines
  • Outstanding rupture strength thanks to cutting-edge injection moulding technique
  • For pipeline installations with serious space restrictions
  • Easy to handle on-site thanks to low weight and compact component dimensions
  • Suitable for heated tool butt welding and electro-socket welding
  • Suitable for Potable Water, Gas & Waste Water

    • Product Range
  • SDR 33 - OD 110mm - 500mm
  • SDR 17 - OD 63mm - 500mm*
  • SDR 11 - OD 20mm - 500mm*
  • * Stub flanges up to OD 710mm
