SITRANS - Field Transmitters

SITRANS TF is available in your choice of a rugged die-cast aluminum or durable stainless-steel housing. It measures signals from resistance thermometers, resistance-type sensors, thermocouples and voltage sensors, and converts the signal into direct current signal or bus signal (Profibus PA or Foundation Fieldbus) in accordance with the sensor characteristics.

The SITRANS TF280 is a field temperature transmitter that transmits the process value per Wireless HART communication.

We offer a range of Field Transmitters Products.

This range includes,

  • SITRANS TF
    •
  • SITRANS TF280
    •

    SITRANS TF

    SITRANS TF is used where other transmitters can't cope. One main point is its rating of IP67.

    SITRANS TF is made of rugged die cast aluminum or long-lasting stainless steel. It transforms resistance thermometers, thermocouples, Ohm and mV signals into a load independent DC current corresponding to sensor characteristic or a digital signal according Fieldbus standard Profibus PA or Foundation Fieldbus. The remote mounted sensor prevents the transmitter heating up at high temperature; there are no vibrations and oscillations due to long neck tubes and protective pipes with SITRANS TF.

    For tags with difficult access to you can mount your SITRANS TF remotely at easily accessible places and display the measured value on the freely programmable digital display (with version 4 to 20 mA).

    You can even use the SITRANS TF in a version without a transmitter as a comfortable field display unit for all 4 to 20 mA signals.

    All SITRANS TF are available in intrinsically safe or explosion proof version

    Benefits
  • Local sensing of measured values over digital display
  • Rugged two-chamber enclosure in die-cast aluminium or stainless steel
  • Test terminals for direct read-out of the output signal without breaking the current loop


    • Details
  • Input - Resistance thermometers, Thermocouples, Resistance-type sensors, DC sources
  • Output - Versions for: 4 to 20 mA, 4...20 mA with HART, Profibus PA or Foundation Fieldbus

    • SITRANS TF280

    The SITRANS TF280 is a WirelessHART temperature transmitter that provides all measured process values as well as diagnostic information, parameters and functions via radio. The device is powered by an internal battery and designed for ultra low power consumption. Its compact and rugged design makes it specially suitable for direct mounting on tanks and pipes in remote parts of plants, and on moving or rotating equipment for process monitoring or asset management applications.

    Benefits
  • LCD display with functional display items and icons, English and German display selectable
  • Practical push buttons: Three push buttons for maximum efficiency for setup, diagnostics, communication and security settings with no additional devices or tools
  • Maintenance-friendly backlight function
  • Sleep mode for efficient battery life management
  • Battery status display on LCD and in network overview
  • Precise measurement accuracy for more productivity
  • 90 and 180 degree display turnable
  • Configurable with standard tools which support EDD – e. g. with SIMATIC PDM
  • Extension cable for separate installation of the sensor
  • Physical HART maintenance port for commissioning


    • Details
  • Input - Pt100 (IEC 60751)
  • Output - WirelessHART radio in 2.4 GHz
