For reliable restraint connections on all types of pipe materials. The MULTI/JOINT 3000 Plus wide range system meets the demands and is suitable for applications in water and gas for pipe sizes from DN50 up to and including DN600.
Model 3107:
Suitable for all kinds of pipe material
Suitable for water and gas
Ductile Cast iron GGG45 body and clamping ring(s), acc. to EN-GJS-450-10
RESICOAT® epoxy powder coating, according to GSK standards and EN 14901
NBR or EPDM gasket, NBR acc. to EN 682 (-5°C up to +50°C), EPDM acc. to EN 681-1 (0°C up to +50ºC)
Angular deflection of max. 8º per socket at installation (based on the middle of the coupling range)
Stainless steel A4 quality (AISI 316) Uni/Fiksers
Stainless steel A2 quality (AISI 304) bolts, nuts and washers (optional: A4 quality)
For restraint versions, on plastic pipes, the use of an insert stiffener (see accessories) is mandatory, check our technical information
Hygiene protection included DN50 - DN600
* MULTI/JOINT® 3000 Plus sizes DN425 and DN475 available Q1 2017. Please contact us for more information
Multi/Joint 3107
MULTI/JOINT Technical Specifications
| DN (mm) | Range 1 (mm) | Range 2 (mm) |
|---|---|---|
| 50 ‐ 65 | 46 ‐ 71 | 63 ‐ 90 |
| 65 ‐ 80 | 63 ‐ 90 | 84 ‐ 105 |
| 80 ‐ 100 | 84 ‐ 105 | 104 ‐ 132 |
| 100 ‐ 125 | 104 ‐ 132 | 132 ‐ 155 |
| 100 ‐ 150 | 104 ‐ 132 | 154 ‐ 192 |
| 125 ‐ 150 | 132 ‐ 155 | 154 ‐ 192 |
| 150 ‐ 200 | 154 ‐ 192 | 192 ‐ 232 |
| 200 ‐ 225 | 192 ‐ 232 | 230 ‐ 268 |
| 225 ‐ 250 | 230 ‐ 268 | 267 ‐ 310 |
| 250 ‐ 300 | 267 ‐ 310 | 315 ‐ 356 |
| 300 ‐ 350 | 315 ‐ 356 | 352 ‐ 393 |
| 350 ‐ 400 | 352 ‐ 393 | 392 ‐ 433 |
| 400 ‐ 425 | 392 ‐ 433 | 432 ‐ 464 |
| 400 ‐ 450 | 392 ‐ 433 | 450 ‐ 482 |
| 425 ‐ 475 | 432 ‐ 464 | 481 ‐ 513 |
| 450 ‐ 500 | 450 ‐ 482 | 500 ‐ 532 |
| 500 ‐ 550 | 500 ‐ 532 | 548 ‐ 580 |
