We offer a range of System 2000 fittings for PE and PVC pipes, Flanges, Couplings, Duckfoot Bends and End Caps.
Using a lip seal ring for sealing the pipe allows for easier insertion of the pipe into the System 2000 socket
The pipe restraining system is required for pushing the pipe into the seal and chamfer with an appropriate tool
For PE pipes with thin walls (≥ SDR 21) and low internal pressure we recommend using a support liner
Suitable for PE pipes 80/100, EN 12201, DIN 8074
For PVC pipes according to EN ISO 1452-2
Hawle System 2000 Flanged Adapters
System 2000 Fittings
System 2000 - Flange for PE and PVC pipes
With push socket for high-tensile restraint connection with PE and PVC pipes
Flange sized according to EN 1092-2, drilled according to
EN 1092-2 | PN 10 standard; EN 1092-2 | PN 16 DN 200 to DN 600 please specify on order
other standards on request
With integrated flange seal made of elastomer
For DN50 to DN600
System 2000 : Coupling No. 0430
With push socket for high-tensile restraint connection with PE and PVC pipes
With integrated flange seal made of elastomer
For Ø63mm to Ø355mm
Caution! When using as coupling valve: remove stop ring and steeply chamfer pipe (see assembly instructions)
Caution! When using as coupling valve: remove stop ring and steeply chamfer pipe (see assembly instructions)
System 2000 End Cap No 8075
Available with or without axial or radial thread outlet 1" - 2"
BenefitsFor Ø63mm to Ø315mm
