We offer a range of sheet steel Column Pillars and Cabinets.
STANDARD PILLARS:
Three standard sizes available (other sizes on request)
Manufactured in 3mm steel (5mm on request)
Hot-Dipped galvanised
Powder Coated Green as standard to BS 4800 14C39
Cabinet doors fitted with double Tri-Head locks
WBP 18mm plywood backboard fitted
(fully removable when required through the door)
Recessed ‘hidden’ vents & hinges
Earth Strap fitted to door and frame
Door seals rated to IP65
Kiosk Shell manufactured from non-coumbustible materials
All cabinet interiors built to customer specification
Insulation (optional extra)
Insulation Thermal Transmittance rating of 1.5w/m2K
VANDAL RESISTANT:
Tri-Head locks as standard
(other locks on request)
SAFETY FEATURES:
Flush fitting doors
Radiused corners
Ventilated cabinet
Cabinet removable from plinth on site
Earth strap fitted between cabinet and door
Pillars & Cabinets
Pillars & Cabinets Sizes
| CABINET REF #: | IPL-CT01 | IPL-CT02 | IPL-CT03 | IPL-CT04 | IPL-CT05 | IPL-CT06 |
|---|---|---|---|---|---|---|
| Width (cabinet size): | 450mm | 450mm | 1200mm | 600mm | 900mm | 1600mm |
| Height (above ground): | 608mm | 1008mm | 1007mm | 1200mm | 1200mm | 1200mm |
| Depth (external size): | 300mm | 300mm | 400mm | 400mm | 400mm | 400mm |
| Root (below ground): | 300mm | 300mm | 380mm | 300mm | 300mm | 300mm |
| Number of doors: | 1 No. | 1 No. | 2 No. | 1 No. | 1 No. | 2 No. |
| Backboard (internal ‘fitting’ size): | 400x480mm | 400x880mm | 1150x880mm | 500x1040mm | 800x1040mm | 800x1440mm |
| Depth (internal ‘working’ size): | 265mm | 265mm | 365mm | 370mm | 370mm | 370mm |
