We offer a range of five different modular inspection chamber systems – Ecolite, Atlas, EasyStack, EasyLiner and STAKKAbox – which are suitable for different areas of the construction industry. These are able to withstand different load bearing strengths of up to 90 tonnes. The components of the chamber systems are made from recycled plastic and can be recycled at end of use and are available in many different chamber sizes.
Ecolite
Atlas
EasyStack
EasyLiner
Stakkabox
Modular Inspection Chamber Systems
Modular Inspection Chambers Range
Ecolite
Ecolite is a modular inspection chamber system which is ideal for water utilities and many other applications. This system is able to sustain 40 tonnes loading (with 60 tonnes and 90 tonnes in some of the larger sizes) and is in the sizes 150x150mm, 380x230mm, 430x280mm, 450x600mm, 600x600mm, 750x600mm and 900x600mm available.
Larger sizes available on request.
Available in a range of sizes
320mm Height
Wall thickness 40mm (150x150mm)
Wall thickness 65mm (380x230mm, 430x280mm)
Wall thickness 90mm (for larger sizes)
Knockouts to suit 60mm, 110mm & 180mm Pipe
Can be drilled to suit other diameters
Lightweight but Extremely Strong
Interlocking components
Made from Polypropylene (PP)
Can be supplied Fully Assembled
Made from recycled plastic
Fully recyclable at end of life
Larger sizes available on request.
Atlas
The parts of the Atlas chamber system are manufactured from recycled polypropylene and have knock-outs for 110mm ducting.
The system is available in various sizes and can withstand loadings from 12.5 tonnes (with larger chambers over 25 tonnes)
Can be supplied with larger pre-drilled duct entry holes to meet site specific requirement.
B125 rating - can be reinforced to D400
Available in 5 sizes 300mm, 450mm, 600mm, 750mm & 900mm
75mm Wall Thickness
Knockouts suit 110mm Pipe
Can be drilled to suit other diameters
Lightweight but Extremely Strong
Interlocking components
Made from Polypropylene (PP)
Can be supplied Fully Assembled
Made from recycled plastic
Fully recyclable at end of life
EasyStack
EasyStack is a twin-walled inspection chamber system which is manufactured from recycled polypropylene. This chamber system can withstand loads of up to 90 tonnes which makes it suitable for almost all areas of the construction industry, including airport and dockyard installations.
The parts of the walls are available in the sizes of 300mm, 450mm, 600mm, 750mm, 900mm and so on and can therefore be assembled into larger chambers with walls up to several meters long. It can also be strengthened with steel parts to make chambers resistant to high lateral loads.
EasyStack’s duct entry options are available with 110mm entries pre-formed and with 110mm knockouts, but can also be supplied with larger pre-drilled duct entries to meet specific site requirements.
B125 rating - can be reinforced to D400
Available in 5 sizes 300mm, 450mm, 600mm, 750mm & 900mm
75mm Wall Thickness
Knockouts suit 110mm Pipe
Can be drilled to suit other diameters
Lightweight but Extremely Strong
Interlocking components
Made from Polypropylene (PP)
Can be supplied Fully Assembled
Made from recycled plastic
Fully recyclable at end of life
EasyLiner
EasyLiner is a lightweight yet rigid chamber which can be easily assembled. All components lock together, making EasyLiner a robust chamber which is suitable for a variety of uses.
This chamber system is normally concrete back filled and offers an alternative to rotationally moulded liners, over which EasyLiner has cost and technical advantages.
Available in 3 sizes 300mm, 450mm & 600mm
320mm Height
Knockouts to suit 60mm, 110mm & 180mm Pipe
Can be drilled to suit other diameters
Lightweight but Extremely Strong
Interlocking components
Made from Polypropylene (PP)
Can be supplied Fully Assembled
Made from recycled plastic
Fully recyclable at end of life
STAKKAbox™ Modula
The STAKKAbox™ system is a range of polypropylene preformed twin wall modular access chambers. They have been developed for use in both footway and carriageway installations and are capable of withstanding vertical loads in excess of 40 tonnes without the requirement for any structural support.
The Modula Access Chamber consist of 155mm deep stacking sections which can be stacked on top of each other to form complete chambers of any depth. The STAKKAbox™ access chamber system has a high strength to weight ratio. This is due to its unique patented twin wall design with internal vertical and horizontal support ribs. The vertical ribs provide a high degree of vertical compressive strength that resists the loads applied by vehicles passing over, while the continuous horizontal rib offers a strong resistance to side wall loads from vehicle or ground heave.
STAKKAbox modular Access Chambers range in size from 300 x 300mm to 1200 x 1200mm clear opening and can be provided with or without pre drilled duct entry points of any size. The chamber system provides contractors with a means of constructing access chambers quickly and inexpensively, whilst offering improved build quality, reduced defects and enhanced site safety performance.
The STAKKAbox access chamber is suitable for use in a number of different areas including traffic signals, street lighting, motorway communications, rail infrastructure or your own bespoke applications.
Product Features
40 tonne vertical loading for both carriageway and footway application
Lightweight – all section under 20kg
All weather construction
Smooth internal walls
Simple and rapid installation
No concrete surround required
Easily adaptable to overcome existing services
Specialist lifting equipment is not required
