Clamp-on Range

SITRANS FST020

SITRANS FST020 offers reliable flow measurement at a much lower cost than other clamp-on ultrasonic flowmeters, with flow rate accuracy of ± 0.5 % to 1.0 % for most applications.

Benefits
  • Easy installation; no need to cut pipe or stop flow
  • Minimal maintenance; external sensors do not require periodic cleaning
  • No moving parts to wear or foul
  • No pressure drop or energy loss
  • Compact, integral design reduces installation cost
  • Wide turn-down ratio
  • Optional WideBeam technology ensures high performance
  • ZeroMatic Path automatically sets zero without stopping flow and eliminates zero drift

  • SITRANS FUE1010

    SITRANS FUE1010 is a highly accurate clamp-on non-intrusive ultrasonic flow transmitter for revenue grade thermal energy sub-metering and energy efficiency distribution monitoring, with a real time coefficient of performance (COP) for HVAC systems.

    SITRANS FUE1010 is available in single and dual channel or dual path configurations, with your choice of IP65 (NEMA 4X) dedicated wall mount or IP40 (NEMA 1) portable enclosures.

    Benefits
  • Measures energy rate and total consumption with highest accuracy available
  • Accurately measures at both low flow rates and low differential temperatures
  • Easy installation; no need to cut pipe or stop flow
  • Minimal maintenance; external sensors do not require periodic cleaning
  • No moving parts to foul or wear
  • No pressure drop or energy loss
  • Wide turn-down ratio
  • Choice of single or dual channel/dual path or dual mode operation:
  • Dual channel operation reduces the cost for the system on a per channel measurement basis and permits measuring hot and chilled water lines at the same time
  • Dual path capability insures high flow measurement accuracy on installations with less than desirable piping runs
  • Ability to operate in either Wide-Beam Transit-time or reflexor (Doppler) mode for applications with high aeration
  • ZeroMatic Path automatically sets zero without stopping flow and reduces zero drift, even at low flow

  • SITRANS FUP1010 (Portable)

    SITRANS FUP1010 clamp-on non-intrusive ultrasonic flow transmitter offers maximum versatility plus battery power for portable field use. It can operate in either WideBeam transit time or reflexor (Doppler) mode, making it suitable for virtually any liquid, even those with high aeration or suspended solids.

    SITRANS FUP1010 is available in single and dual channel or dual path configurations, with IP67 weatherproof enclosure.

    Benefits
  • Battery power facilitates field use; the meter is easily transported from one installation to another – saving time for surveys, monitoring and temporary installations
  • Weatherproof enclosure can be used outdoors and left in place without concern for rain damage
  • Rugged plastic case enables it to withstand rough treatment that would destroy most other meters
  • Versatility - there is no need to change meters when operating conditions change
  • Easy installation; no need to cut pipe or stop flow
  • Minimal maintenance; external sensors do not require periodic cleaning
  • No moving parts to wear or foul
  • No pressure drop or energy loss
  • Wide turn-down ratio
  • Choice of single or dual channel models minimizes total cost
  • ZeroMatic Path automatically sets zero without stopping flow and reduces zero drift, even at low flow
  • Note that the SITRANS FUP1010 flow transmitter is not available with hazardous area approvals
  •
