Overcoming any pipe connection problem in water and gas systems. Reducing stocks and last but not least, increasing the quality of the connection and the reliability of your system.
That is what we offer you with our MULTI/JOINT XL system for pipe sizes from DN300 up to and including DN600.
Model 2650:
Suitable for all kinds of pipe material
Suitable for water and gas
Ductile Cast iron GGG45 body and clamping ring(s), acc. to EN-GJS-450-10
RESICOAT® epoxy powder coating, according to GSK standards and EN 14901
NBR or EPDM gasket, NBR acc. to EN 682 (-5°C up to +50°C), EPDM acc. to EN 681-1 (0°C up to +50ºC)
Angular deflection of max. 4º per socket at installation (based on the middle of the coupling range)
Stainless steel A2 quality (AISI 304) bolts, nuts and washers (optional: A4 quality)
Other dedicated sized couplings up to 2800 mm on request
For all plastic pipes, the use of an insert stiffener (see accessories) is advised or in some cases mandatory, check our technical information.
Multi/Joint 2650
MULTI/JOINT Technical Specifications
| DN (mm) | Range 1 (mm) | Flange 2 (mm) | Drilling Pattern |
|---|---|---|---|
| 450 ‐ 400 | 450 ‐ 482 | 400 | PN10 |
| 450 ‐ 400 | 450 ‐ 482 | 400 | PN16 |
| 550 ‐ 500 | 548 ‐ 580 | 500 | PN10 |
| 550 ‐ 500 | 548 ‐ 580 | 500 | PN16 |
