Hawle Hawex - Pipe Drilling Saddle - No. 5270
For PE and PVC pipes:
PN10/PN16 (DIN 8074, 8061/8062)
For potable water
Design features:
Robust design of ductile iron with epoxy powder coating
Bolts, nuts and washers are made of Class A2 stainless steel
The drilled hole is sealed with the O-ring mounted in the top section saddle
The saddle lower section is provided with a glued-on rubber gasket
Material:
Saddle body: ductile iron EN-GJS-400-18, according to EN 1563 (GGG 400 - DIN 1693), with epoxy powder coating
Rubber gasket: EPDM
O-ring: EPDM
Bolts, nust and washers: Class A2 stainless steel
Nuts: treated with molybdenum sulphide
PN10/PN16 (DIN 8074, 8061/8062)
